| Battery Model: | RN-12V-120Ah |
| Total Energy： | 1440Wh |
| Nominal Capacity： | 120ah |
| Minimum Capacity： | 120AH |
| Nominal Voltage： | 12V |
| Charging Voltage： | 14.4V |
| Charging Protection Voltage： | 14.4V |
| Discharging Cut-off Voltage： | 12v |
| Discharging Rrotection Voltage： | 10V |
| Charging Protection Voltage： | 14.4v |
| Over current protection： | 300A |
| Standard Charging Current: | 20A |
| Maximum Charging Current： | 50A |
| Charing Cut-off Current： | 0.02C |
| Standard Dischaging Current | 20A |
| Maximum Charging Curren： | 100A |
| Max.Continuous Charge Current： | 30A |
| Max.Continuous Discharge Current | 50A |
| Operating Temperature（Charging/Discharging）： | 0~45℃/ -20~60℃ |
| Battery Weight(Approx)： | 6KG |
| Battery Cells： | We provide solutions or according to customer requirements |
| Requirements For Input And Output Ports： | Set this parameter based on the actual situation |
| Storage Temperature | -10℃~50℃ |
| Battery Dimension： | |
| Length: | 182mm |
| Width： | 155mm |
| Thickness： | 175mm |
| Storage Environment： | Battery should be stored in a cool, dry and well-ventilated area, and should be far from the fire and the high temperature. |
RN-12V-120Ah
